Megaphone

The ACR EM-1A, EM-2BA, and EM-1D Portable Safety Megaphones have been designed to minimize acoustic feedback that results in whistling and other similar sounds. Each megaphone has a 90° sound projection angle so that people in the megaphone’s immediate vicinity, as well as those in the rear sections of an aircraft, can hear the message. Plus, the amplifier frequency band-pass has been selected to produce a crisp, clear reproduction of voice signals. Specific attention has been given to the physical size of the megaphone so that each model can be used effectively in a crowded environment.

PRODUCT DESCRIPTION

The ACR/EM-1A, ACR/EM-2BA, and ACR/EM-1D have been designed to minimize regenerative acoustic feedback that results in whistling and other oscillations of this nature. They have a 90° sound projection angle to direct the sound to persons in their immediate vicinity, as well as in the rear sections of any aircraft. The amplifier frequency band-pass has been selected to produce a crisp, clear reproduction of voice signals. The operating power level is also sufficient to provide adequate sound under high ambient noise level conditions without being overpowering. Specific attention has been given to the physical size so that they can be used effectively in a crowded environment. Only available through Kellstrom Aerospace.

Additional information

Weight	0.00 lbs
Aircraft Type	Airliners, Mid-size Jets, Passenger Jet
Product	Megaphones

Product Number	2204; 2206; 2208
Dimensions	5.5” max diameter bell, 11.5” max long
Weight	2.3 lbs., including batteries
Materials	Horn, handle – Anodized AluminumHousing – Aluminum
Gain Control	Thumb operated
Amplifier	Integrated circuit, 2 watts power output
Speaker	Re-entrant horn and driver typeinput power five (5) watts90° dispersion angle
Microphone	High Sensitivity
Batteries	Six (6) standard 1½ volt “AA” cells
Power Drain	12 milliamps static current550 milliamps maximum current
Frequency Response	500 to 3500 Hz
Anti-Removal Alarm (ACR/EM-1A only)	Warbling tone 500 – 1200 HzPlug pin, retained by nylon cord
Battery Test Circuits	Visual Flashing Green LEDAcoustical Beep (ACR/EM-1D only)

WARRANTY LENGTH: 1 YEAR

This product is warranted against factory defect in material and workmanship for a period of 1 (one)* year from date of purchase or receipt as a gift. During the warranty period ACR Electronics, Inc. will repair or at its option, replace at no cost to you for labor, materials or return transportation.
For further assistance, please contact our Technical Service Department at :

ACR Electronics, Inc.

5757 Ravenswood Road, Fort Lauderdale, FL 33312-6645

Email: service@acrelectronics.com

Telephone: +1 (954) 981-3333

Fax: +1 (954) 983-5087

This warranty does not apply if the product has been damaged by accident or misuse, or as a result of service or modification by other than the manufacturer. The COMPANY MAKES NO REPRESENTATION OR WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, AS TO MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR ANY OTHER MATTER WITH RESPECT TO THIS PRODUCT, except as otherwise expressly stated in the previous paragraph. The Company shall not be liable for consequential or special damages. In order to place the warranty in effect, choose a form above and complete it entirely. Or you may fill out the registration card accompanying your product (if applicable) which must be returned to ACR Electronics, Inc. within ten days of purchase.
